High-definition video surveillance system represents the image of the advantages of the image

The representation of high-definition camera images has always been measured by resolution, and the horizontal resolution is continuously improved while maintaining the same scanning format. HDTV cameras are different. They require image resolution to be doubled in the horizontal and vertical directions compared to the average standard TV, and the color and color separation (standard definition is combined by spectrum interleaving technology), so (TV) scanning system, The baseband signal format is different from standard definition TV, and the two are no longer compatible and are not interchangeable. At present, the image output of a high-definition camera is mainly a digital stream.

To promote high-definition surveillance systems, we must first define where HD images can show its advantages. Obviously, the value of high-definition images can be reflected when observing partial images and hoping to obtain image detail information. If the partial image is displayed in full screen, the image still has a high resolution and no mosaic phenomenon; when the electronic police or road bayonet system performs the number plate recognition, a sufficient number of pixels can obtain a higher recognition rate. A high-resolution (pixel) image is an important condition when performing image individual recognition. However, in the normal real-time monitoring environment (viewing distance and displaying dynamic images), the observation effect of HD images and SD images is not much different; when performing image behavior analysis, the frame rate stability (time resolution capability) of images is very demanding. High, but the image (space) resolution requirements are not high. Therefore, when constructing a video surveillance system, it is necessary to analyze the specific problems and adapt to the local conditions. Select the appropriate occasions and parts to adopt high-definition cameras. Do not simply proceed from the concept and make a one-size-fits-all approach.

At present, the high-definition video surveillance system has not yet formed a unified standard (standard), how to realize the complete supporting and unified interface of the camera, transmission, recording, display, image transformation and processing equipment in the system. This is also the problem that HD video surveillance technology should solve as soon as possible. Only by establishing a unified standard and forming a complete package can we achieve the interchangeability and versatility of the equipment of each manufacturer, providing users with more choices.

The most important thing is to solve the integration problem between HD images and standard image systems. They cannot simply be two separate systems to ensure high quality images and high resolution in HD systems. The video surveillance system must perform comprehensive display, recording, and editing of images of various signal sources in the system, down-converting high-definition images, or up-converting standard images. At present, it is rare to see a system that up-converts SD signals. Most systems decode HD image signals into SD format (down-conversion) during image display. Obviously, such a system discounts the image quality of HD cameras.

Summary: After the problem has been solved, I believe that the HD video surveillance system image will be more clear.

The image is full of daylight and noisy

1: Check if the lens aperture is off.

2: Increase the camera illumination.

Lens motor does not work or works slowly

1: Check if the working voltage is enough for dc12v.

2: Is the lens working current enough for 100ma?
